Titan 2

Affordable, easy to use HBM tester

Titan 2 is a new affordable tester that is compact and easy to use. Quickly perform HBM pulses and DC leakage measurements, all from a touchscreen interface.

Titan 2 Features

Low Parasitic 2-Pin Testing

Meets the current ESDA/JEDEC requirements for a Low Parasitic HBM Tester, which reduces the number of stress pulses needed for device classification.

Pulse Delivery Options

Wire Leads

Coax Probes

DUT Boards

Relay-Controlled Automation

Probe Station Integeration

Performance Capabilities

HBM voltage range from 30V to 4kV (optional higher voltages available). Optional current sense, automatic DC leakage measurements. Integrates with Signatone Probe Stations

Convenient Form Factor

Control it from a touchscreen or a Keyboard/Mouse/Monitor. Fits on your workbench or in a 19-inch rack

Modern Software

Newly designed software is easy to configure, logs all data, and is remotely controllable. Fits into existing company workflows

Learn More

Try a live software demo, view the Datasheet, or schedule a demo

Titan 2 Specifications

HBM Pulse Characteristics

HBM Voltage Rage: ±30 V to ±4,000 V Optional higher voltages available
HBM Voltage Resolution: 1 V
Pulse Speed: Positive, Negative, Bipolar User selectable
Charge Removal: 10 KΩ discharge between pulses

Compliance Standards

ANSI/JEDEC/ESDA JS001-2024
AEC Q100-002 REV-E
JEITA ED-4701/300 Method 304
IEC 60749-26
MIL-STD 883E Method 3015.7

Physical Specifications

Power Requirements: 100 - 240 VAC, 50 - 60 Hz, 0.5 A (max)
Operating Temperature: 5° to 35°C (40° to 95°F
Humidity: 10 - 80% RH non-condensing

Trigger & Current Sense

Oscilloscope Trigger Output: 5 V
DUT Current Sense: Optional DUT current measurement (Tek CT-2 characteristics)

Leakage Measurement

Frequency: User selectable Per-Pulse, Per-Polarity, or Per-Voltage
Measurement Unit: Uses External SMU (Force/Limit dependent on SMU selected)
Current and Voltage Limits: 100 pA to 1 A and 500 μV to 200 V, with other SMU range options
